import torch
import torch.nn as nn
import torch.nn.functional as F
import torch.optim as optim
from torch.utils.data import DataLoader
from torchvision import datasets, transforms
import logging
import syft as sy
import torchvision
hook = sy.TorchHook(torch)
qin = sy.VirtualWorker(hook=hook, id="qin")
zheng = sy.VirtualWorker(hook=hook, id="zheng")
#设定参数
args = {
'use_cuda': True,
'batch_size': 64,
'test_batch_size': 1000,
'lr': 0.01,
'log_interval': 10,
'epochs': 10,
'save_model': False
}
use_cuda = args['use_cuda'] and torch.cuda.is_available()
device = torch.device("cuda" if use_cuda else "cpu")
# 我们首先加载数据，然后使用。联邦方法。
# 此联邦数据集现在提供给 Federated DataLoader。测试数据集保持不变。
# 下面是训练数据，需要分发给远处打工人
federated_train_loader = sy.FederatedDataLoader(
datasets.MNIST('./mnist_data', train=True, download=True,
transform=transforms.Compose([
transforms.ToTensor(),
transforms.Normalize((0.1307,), (0.3081,))
]))
.federate((qin, zheng)),
batch_size=args['batch_size'], shuffle=True
)
# federate()函数已经实现了分发（省去了我们一个一个send()的麻烦）
# 下面是测试数据，在我们本地
test_loader = DataLoader(
datasets.MNIST('./mnist_data', train=False,
transform=transforms.Compose([
transforms.ToTensor(),
transforms.Normalize((0.1307,), (0.3081,))
])),
batch_size=args['batch_size'], shuffle=True
)
# CNN网络
class Net(nn.Module):
def __init__(self):
super(Net, self).__init__()
self.conv = nn.Sequential(
nn.Conv2d(in_channels=1, out_channels=32, kernel_size=3, stride=1),
#输出26*26*32
nn.ReLU(),
nn.Conv2d(in_channels=32, out_channels=64,kernel_size=3, stride=1),
#输出24*24*64
nn.ReLU()
)
self.fc = nn.Sequential(
nn.Linear(in_features=64*12*12, out_features=128),
nn.ReLU(),
nn.Linear(in_features=128, out_features=10),
)
self.dropout = nn.Dropout2d(0.25) # 随机丢弃
def forward(self, x):
x = self.conv(x)#输入的时候是28*28*1,输出应该是24*24*64
x = F.max_pool2d(x, 2)#用步长为2的池化,输出12*12*64
x = x.view(-1, 64*12*12)#此时将其拉成一条直线进入全连接
x = self.fc(x)
x = F.log_softmax(x, dim=1)
return x
def train(args, model, device, train_loader, optimizer, epoch):
model.train()
# 远程迭代
# for batch_idx, (data, target) in enumerate(federated_train_loader):
# if batch_idx < 5:
# print(batch_idx, type(data), data.location)
# else:
# break
# 0 <class 'torch.Tensor'> < VirtualWorker id:qin # objects:4>
# 1 <class 'torch.Tensor'> < VirtualWorker id:qin # objects:4>
# 2 <class 'torch.Tensor'> < VirtualWorker id:qin # objects:4>
# 3 <class 'torch.Tensor'> < VirtualWorker id:qin # objects:4>
# 4 <class 'torch.Tensor'> < VirtualWorker id:qin # objects:4>
for batch_idx, (data, target) in enumerate(train_loader): # enumrate用来编序号
# model = model.send(data.location) # 发送模型到远程
model.send(data.location)
data, target = data.to(device), target.to(device)
optimizer.zero_grad()
output = model(data)
loss = F.nll_loss(output, target)
loss.backward()
optimizer.step()
# 以上都是发送命令给远程，下面是取回更新的模型
model.get()
if batch_idx % args['log_interval'] == 0: # 打印间隔时间
# 由于损失也是在远处产生的，因此我们需要把它取回来
loss = loss.get()
print('Train Epoch:{}[{}/{}({:.06f}%)]\tLoss:{:.06f}'.format(
epoch,
batch_idx * args['batch_size'],
len(train_loader) * args['batch_size'],
100. * batch_idx / len(train_loader),
loss.item()
))
def test(model, device, test_loader):
model.eval()
'''返回model的返回值以字符串显示,使用PyTorch进行训练和测试时
一定注意要把实例化的model指定train/eval，eval（）时，
框架会自动把BN和DropOut固定住，不会取平均，而是用训练好的值，不然的话，
一旦test的batch_size过小，很容易就会被BN层导致生成图片颜色失真极大！！'''
test_loss = 0 #测试损失
correct=0 #正确率
with torch.no_grad():
for data,target in test_loader:
data,target = data.to(device),target.to(device)
output=model(data)
#将损失加起来
test_loss+=F.nll_loss(output,target,reduction='sum').item()
'''nll_loss的解释请看
https://blog.csdn.net/qq_22210253/article/details/85229988
和https://www.cnblogs.com/ranjiewen/p/10059490.html'''
#进行预测最可能的分类
pred =output.argmax(dim=1,keepdim=True)
correct+=pred.eq(target.view_as(pred)).sum().item()#???
test_loss/=len(test_loader.dataset)
print('\nTest set: Average loss: {:.4f}, Accuracy: {}/{} ({:.0f}%)\n'.format(
test_loss, correct, len(test_loader.dataset),
100. * correct / len(test_loader.dataset)))
model = Net().to(device)
optimizer = optim.SGD(model.parameters(), lr=args['lr'])
logging.info("开始训练!!\n")
for epoch in range(1, args['epochs']+1):
train(args, model, device, federated_train_loader, optimizer, epoch)
test(model, device, test_loader)
# if (args["save_model"]):
torch.save(model.state_dict(), "mnist_cnn.pt")
|
